Non-invasive EEG electrode patches

Product name
Single-use non-invasive EEG electrode patches
High-density signal capture | Zero conductive paste design | Suitable for all ages

1. Product Overview
Material Composition:

Conductive layer: nano-silver-hydrogel composite colloid (impedance≤2kΩ, support 0.5-100Hz band signal capture)

Substrate: ultra-thin medical silicone film (thickness 0.03mm, elongation ≥ 400%, suitable for head curved surface)

Backing: Breathable mesh release liner (precision positioning 10-20 system)

Scope of application:
Electroencephalogram (EEG) testing, epilepsy monitoring, sleep studies, brain-computer interface (BCI) and neurofeedback therapy.

Applicable scenarios: Neurology departments, scientific research laboratories, and home remote brain health monitoring in tertiary hospitals

Second, the core advantages
1. Accurate capture of EEG signals
High-density sensing: Electrode contact impedance ≤ 2kΩ (1kHz test), signal-to-noise ratio ≥70dB, and supports α/β/θ/δ wave separation analysis.

Zero-conductive paste design: Pre-applied long-lasting hydrogel eliminates the need for traditional EEG paste application steps and shortens preparation time by 80%.

Anti-motion artifacts: patented flexible substrate + dynamic filtering technology to suppress blinking, chewing and other action interference (artifact rate <5%).

2. Customized service (stand-alone module)
Customized projects Options
Electrode Layout Standard 10-20 System (19 leads), High Density 64 Leads, Pediatric Mini Array (8 leads)
Adhesive type: hypoallergenic medical adhesive (conventional), reusable adhesive (multiple scientific research tests), water-soluble adhesive (rapid removal for infants and young children)
Wire interface: spring clip type (traditional EEG machine), magnetic quick release type (brain-computer interface device), wireless Bluetooth transmission module (optional)
Packing: Single-piece stand-alone sterilization package (clinical), multi-piece economical package (scientific research), customized lead combination package (e.g., temporal lobe focused monitoring)
3. Global Compliance Certification (Certification Icon Wall)
Special certifications: IEC 60601-2-26 (safety standard for EEG machines), ISO 10993-10 (skin sensitization test)

Basic certification: CE MDR, FDA 510 (k), NMPAIII

Research compliance: EMG/EEG data collection ethics certification (support for data traceability of scientific research papers)

3. Technical parameter table
Project parameters
Input Impedance: ≤2kΩ (1kHz, IEC 60601-2-26 standard)
The frequency response range is 0.5-100Hz (±3dB), and it supports low-frequency δ wave capture (0.5-4Hz).
Baseline noise ≤1μVpp (24-hour continuous monitoring)
Adhesion durability 72 hours (measured adhesion to scalp oil environment≥ 0.6N/cm²)

ECG patches have CE and other multi-national certifications, can be sold worldwide, and can accept customized services, including but not limited to shape, material, brand and box size, etc. We are committed to meeting the needs of our customers
